SR307 is simple to fit to Sundstrom half masks and full face masks.
The airflow rate can be controlled by means of the regulating valve on the users belt to a value between about 150 and 320 l/min.
The supply pressure to the regulating valve should be between 4 and 6 bar. A flow meter and a warning whistle for temporary and continuous monitoring of the airflow are included.
SR200 Airline with filter backup is a breathing apparatus that provides a continuous airflow when connected to compressed air. It has been specially produced for heavy, prolonged work or where pollutants are especially unhealthy and a high degree of protection is required.
The breathing hose can be detected from both mark and regulator valve. The air quantity can be regulated to between about 150 and 320 l/min at a working pressure of 5-7 bar.
In the A model) the breathing hose can be detected from both mask and regulator, whereas in the B model) the breathing hose is permanently attached to the mask and can only be detected from the regulator.
The Anest Iwata Airfed 2100 has been developed with the operator in mind. The mask is functional, stylish, comfortable and lightweight. The Airfed Mask is a positive pressure safety device to unsure no air borne contaminants can enter the air breathing space.
Please see attached flyer for more information
The MPV supplied air vizor has a lightweight fully adjustable headband and browguard. The neck and ears are also protected with a disposable cover. The detachable acetate vizor has a flexible face skirt incorporating a diffused compressed air feed tube. The vizor can be lifted up from the face when the operator is not working in a hazardous area. Two half turn tension knobs adjust the vizor movement.
Please see attached pdf for information.
Fine tapered broach for cleaning blocked tips.
Packet of 12.
Stiff bottle brush for cleaning tips and guns
For filled materials that cause tip plugging such as high solids coatings and fibrous mastcis.
General spray tip for all common coatings.
Thin (25 per package: 223-373)
For use with flat tips or accessory attachments.
Provides a seal between the gun and spray tip or other attachments.
Extra Large Tip Guard for Heavier Coatings
Use only with XHD-010 Tips
Use with all RAC tips (221XXX, 286XXX, LL5XXX & FFTXXX).
Provides a swivelling joint between gun and hose for free gun movement.
Installs at gun inlet.
Working Pressure – 5800 psi (400 bar, 40.0 Mpa) max.
Fluid Inlet – 1/4″ npsm(m).
Fluid Outlet – 1/4″ npsm(f).
Filters fluid before it enters the gun.
Helps reduce tip plugging; provides better finish quality.
Attaches to hose and connects to the gun inlet.
Contains one filter (equivalent to 50 mesh and 100 mesh screen).
Working pressure – 5000 psi (345, 34.5 MPa) max.
Fluid Inlet – 1/4″ npsm(m)
-Fluid Outlet- 1/4″ npsm(f)
